NoWeld Spring Assisted Swing Gate

Click and drag image to view 360˚

A self-closing pedestrian swing gate designed to complement the NoWeld modular system.

Seeking a budget-friendly swinging gate option to supplement your NoWeld Handrail and Guardrail System? Need a solution for your industrial or commercial space, such as a swinging gate that meets Australian Workplace Safety Standards? Or perhaps you are after a hinged gate replacement?

Whatever the need, know that the NoWeld Spring Assisted Swing Gate offers a reliable barrier for pedestrian walkways, ensuring workplace safety by separating pedestrians from moving vehicles in busy industrial environments like warehouses and factories.

The NoWeld Spring Assisted Swing Gate can be installed quickly and easily by DIY. Enriched with a powered-coated aluminium hoop for lighter operational weight and prolonged life, it can be cut to size to fit your industrial and commercial safety needs.

Our NoWeld safety fence gates offer a self-closing mechanism, and robust plastic gate stops that minimise damage compared to metal stops. Additionally, the NoWeld Swing Gate comes with a plastic handle with both push and pull labels, providing pedestrians with an understanding of how to use it.

You can create a manual access gate or removable panel by combining the Gate Hinge Pin with the Gate Eye.Suitable for indoor and outdoor projects, it offers a convenient slip-on connection feature that requires only a hex key to secure it.

Indoor and outdoor tested. Suitable for industrial and commercial settings. Supplements the NoWeld Modular Handrail System – Often used for walkways, warehouses and zone segregation. Budget-friendly.

  • NoWeld Spring Assisted Swing Gate

    PR-Rail Gate
    Code Image Product Name Stock Level
    NWSSG
    PR-Rail Gate Assembly

  • Colour: Safety Yellow
    Finish: Powdercoated
    Operation: Spring Assisted
    Construction: Aluminium and Galvanised Steel
    Gate Swing: 180 degrees
    Gate Stop: Built in
    Gate Latch: No
    Hold Open: No
    Receiver Post: Optional
    Span Width: Max 1670mm Min 690mm
    Max Opening: 1530mm
    Min Opening: 550mm
    Mounting Type: Post Only 48-50mm or 73mm
    Gate Frame: 40NB (48.3mm)
    Gate Hoop: 32NB (42.4mm)
    Gate Height: 1000mm Above Floor
    Weight: 7.4kg
